dhxpyt

DHX PyTincture WASM Based Widgetset

DHX PyTincture Widgetset Logo

Overview

The DHX PyTincture Widgetset is a Python library that integrates DHTMLX JavaScript UI components with the pyTincture framework using Pyodide. It enables building interactive, browser-based user interfaces directly in Python, supporting cross-platform GUI development with rich widgets like grids, charts, and forms.

Features

  • Direct integration with DHTMLX UI components
  • Pyodide-powered Python execution in the browser
  • Cross-platform compatibility
  • Customizable and reusable widgets
  • Event handling for interactive experiences

Detailed class and API documentation is available in the sidebar.

Installation

Prerequisites

  • Python 3.13+
  • Pyodide

Steps

  1. Clone the repository:
    bash git clone https://github.com/pytincture/dhx_pytincture_widgetset.git cd dhx_pytincture_widgetset;

QuickStart

Windows

Install UV / pytincture / dhxpyt on Powershell

powershell -c "irm https://astral.sh/uv/install.ps1 | iex"
$env:Path += ";$env:USERPROFILE\.cargoin"
[Environment]::SetEnvironmentVariable("Path", $env:Path, [System.EnvironmentVariableTarget]::User)
$env:Path = [System.Environment]::GetEnvironmentVariable("Path", [System.EnvironmentVariableTarget]::User)
New-Item -ItemType Directory -Name dhxpyt_quickstart; Set-Location dhxpyt_quickstart
uv venv --python 3.13; .\.venv\Scripts\Activate.ps1
uv pip install dhxpyt pyodide-py js pytincture itsdangerous
Invoke-WebRequest -Uri https://pytincture.com/quickstart.py -OutFile quickstart.py
$env:PYTHONUTF8 = "1"
uv run quickstart.py

Linux / MacOS

Install UV / pytincture / dhxpyt on Bash

curl -LsSf https://astral.sh/uv/install.sh | sh
echo 'export PATH="$HOME/.cargo/bin:$PATH"' >> ~/.bashrc
source ~/.bashrc
uv --version
mkdir dhxpyt_quickstart;cd dhxpyt_quickstart
uv venv --python 3.13 && source .venv/bin/activate
uv pip install dhxpyt pyodide-py js pytincture itsdangerous
curl -O https://pytincture.com/quickstart.py
uv run quickstart.py

Open in Browser: http://localhost:8070/quickstart

Example Code

import sys
from dhxpyt.layout import MainWindow, Layout, LayoutConfig, CellConfig
from dhxpyt.toolbar import ButtonConfig, ToolbarConfig
from dhxpyt.sidebar import NavItemConfig, SidebarConfig
from dhxpyt.grid import GridConfig, GridColumnConfig
from pyodide.ffi import create_proxy

# Sample data for the grid
SAMPLE_DATA = [
    {"id": 1, "name": "Item 1", "value": 100},
    {"id": 2, "name": "Item 2", "value": 200},
    {"id": 3, "name": "Item 3", "value": 300}
]

class QuickstartMain(Layout):
    layout_config = LayoutConfig(
        type="line",
        cols=[
            CellConfig(id="sidebar", width="auto"),
            CellConfig(id="content")
        ]
    )

    def load_ui(self):
        # Sidebar configuration
        sidebar_items = [
            NavItemConfig(id="hamburger", icon="mdi mdi-menu"),
            NavItemConfig(id="items", value="Items", icon="mdi mdi-view-list")
        ]
        sidebar_config = SidebarConfig(data=sidebar_items, collapsed=False)
        self.sidebar = self.add_sidebar(id="sidebar", sidebar_config=sidebar_config)
        self.sidebar.on_click(create_proxy(self.handle_sidebar_click))

        # Content layout with toolbar and grid
        content_layout_config = LayoutConfig(
            type="line",
            rows=[
                CellConfig(id="toolbar", height="auto"),
                CellConfig(id="grid")
            ]
        )
        self.content_layout = self.add_layout("content", content_layout_config)

        # Toolbar configuration
        toolbar_config = ToolbarConfig(data=[
            ButtonConfig(id="add", value="Add Item", icon="mdi mdi-plus"),
            ButtonConfig(id="refresh", value="Refresh", icon="mdi mdi-refresh")
        ])
        self.toolbar = self.content_layout.add_toolbar(id="toolbar", toolbar_config=toolbar_config)

        # Grid configuration
        grid_columns = [
            GridColumnConfig(id="id", width=100, header=[{"text": "ID"}]),
            GridColumnConfig(id="name", width=200, header=[{"text": "Name"}]),
            GridColumnConfig(id="value", width=150, header=[{"text": "Value"}])
        ]
        grid_config = GridConfig(columns=grid_columns, data=SAMPLE_DATA)
        self.grid = self.content_layout.add_grid(id="grid", grid_config=grid_config)

    def handle_sidebar_click(self, id, event):
        if id == "hamburger":
            self.sidebar.toggle()

class QuickstartApp(MainWindow):
    def load_ui(self):
        self.set_theme("dark")
        self.main_layout = QuickstartMain(parent=self)
        self.attach("mainwindow", self.main_layout.layout)

if __name__ == "__main__" and sys.platform != "emscripten":
    from pytincture import launch_service
    launch_service()
  1"""
  2# DHX PyTincture WASM Based Widgetset
  3
  4<img src="tincture.jpeg" alt="DHX PyTincture Widgetset Logo" width="400" style="display: block; margin: 0 auto;">
  5
  6## Overview
  7
  8The DHX PyTincture Widgetset is a Python library that integrates DHTMLX JavaScript UI components with the pyTincture framework using Pyodide. It enables building interactive, browser-based user interfaces directly in Python, supporting cross-platform GUI development with rich widgets like grids, charts, and forms.
  9
 10## Features
 11
 12- Direct integration with DHTMLX UI components
 13- Pyodide-powered Python execution in the browser
 14- Cross-platform compatibility
 15- Customizable and reusable widgets
 16- Event handling for interactive experiences
 17
 18Detailed class and API documentation is available in the sidebar.
 19
 20## Installation
 21
 22### Prerequisites
 23- Python 3.13+
 24- Pyodide
 25
 26### Steps
 271. Clone the repository:
 28   ```bash
 29   git clone https://github.com/pytincture/dhx_pytincture_widgetset.git
 30   cd dhx_pytincture_widgetset;```
 31
 32## QuickStart
 33
 34## Windows
 35#### Install UV / pytincture / dhxpyt on Powershell
 36```
 37powershell -c "irm https://astral.sh/uv/install.ps1 | iex"
 38$env:Path += ";$env:USERPROFILE\.cargo\bin"
 39[Environment]::SetEnvironmentVariable("Path", $env:Path, [System.EnvironmentVariableTarget]::User)
 40$env:Path = [System.Environment]::GetEnvironmentVariable("Path", [System.EnvironmentVariableTarget]::User)
 41New-Item -ItemType Directory -Name dhxpyt_quickstart; Set-Location dhxpyt_quickstart
 42uv venv --python 3.13; .\.venv\Scripts\Activate.ps1
 43uv pip install dhxpyt pyodide-py js pytincture itsdangerous
 44Invoke-WebRequest -Uri https://pytincture.com/quickstart.py -OutFile quickstart.py
 45$env:PYTHONUTF8 = "1"
 46uv run quickstart.py
 47```
 48
